Shelf LED Display Screen GOB P1.875 LED Price Tags Store Digital Signage
Cost-effective Shelf LED Display Screen GOB P1.875 LED Price Tags Store Digital Signage Factory Vendor.
GOB(Gluing On Board) Shelf LED display well Waterproof, Dustproof, Anti-static and collision with excellent video performance for supermarket.
Best resolution maximize eyeballs catching achieved in a limited place for retail store.
Yonwaytech shelf led display available more optional pixel in 1.25mm,1.56mm with length 600mm/23.62”,900mm/35.43”/1200mm/47.24” by heigh 60mm/2.36″.
Various size can be combined installation to match the different sheleves length.
Super slim and light weight aluminum cabinet with ultraI-low-power consumption in aluminum cabinet well heat dissipation long life span.
Hooks hanging on the shelf directly, seamless splicing with the shelf length simple and friendly installation.
Designed for different types of shelves, it can be placed in shopping malls, pharmacy shops, exclusive retail stores, etc.
Plug&playing advanced system friendly to end user,cluster control via Lan / Wifi / APP / 4G optional easy to control without PC and cost saving.
Technical Parameters:
| Pixel Pitch(mm) | P1.8 | P1.5 | P1.2 | ||
| LED Panel | Pixel Configuration | SMD1515 | SMD1212 | SMD1010 | |
| Panel Surface Treatment | GOB(Gluing On Board) | ||||
| LED Drive Power | 32S | 40S | 48S | ||
| Panel Resolution | 32*160(H*L) | 40*200 (H*L) | 48*240 (H*L) | ||
| Panel Size(mm) | 60*300(H*L) | ||||
| Panel Current(A) | 2A – 2.2A | ||||
| Smartshelf LED Banner |
600mm | Resolution | 32*320(H*L) | 40*400 (H*L) | 48*480 (H*L) |
| Shelf Display Size(mm) | L:600mm；H:60mm | ||||
| Power Supply Mode | 24VDC | ||||
| Weight | 1.2 kg | ||||
| Electric Power | 18W Maximum | ||||
| 900mm | Resolution | 32*480(H*L) | 40*600 (H*L) | 48*720 (H*L) | |
| Shelf Display Size(mm) | L:900mm；H:60mm | ||||
| Power Supply Mode | 24VDC | ||||
| Weight | 1.8 kg | ||||
| Electric Power | 27W Maximum | ||||
| 1200mm | Resolution | 32*640(H*L) | 40*800 (H*L) | 48*960 (H*L) | |
| Shelf Display Size(mm) | L:1200mm；H:60mm | ||||
| Power Supply Mode | 24VDC | ||||
| Weight | 2.6 kg | ||||
| Electric Power | 48W Maximum | ||||
| Shelf LED Display | Working Temperature(ºC) | -10ºC—+50ºC | |||
| Thickness | 22mm | ||||
| Luminance(cd/㎡) | ≥500cd/㎡ | ||||
| Working Humidity(RH) | 20%—90% | ||||
| Contrast Ratio | 5000:1 | ||||
| Horizontal Viewing Angle(Deg) | 160° | ||||
| Vertical Viewing Angle(Deg) | 160° | ||||
| Life Span(H) | 100,000 hours (50% brightness) | ||||
| Grey Scale(bit) | ≧14 bit | ||||
| Refresh Frequency(Hz) | 3840 Hz | ||||
