Outdoor P2.9 P3.9 P4.8 P6.2 P7.8 P10.4 Squared Slim & Light Weight LED Display Dual Service IP65

Squared LED screen offers various pixel pitches ranging from P2.9 to P10.42.

Yonwaytech Squared LED display with aluminum cabinet is designed to be 22.5kgs/m²,

Lighter than conventional cabinets (28kg/m² by aluminum and 45kg/m² by iron) in the market.

Lightweight cabinets made of extrusion aluminum material which can significantly reduce cost from transportation and more convenience for installation, but also brings perfect screen evenness.

1000mmx1000mmx83mm sleek design LED panel ensuring a lightweight and making it easier to install and dismantle size into big screen of different dimensions.

In order to fit some special screen sizes, we can also make 1000mm x 500mm panel size,

 1000mm x 750mm panel size,

 500mm x 1000mm panel size or even 500mm x 750mm panel size,

 various size cabinets can be combined installation to match the different screen size you need.

The pixel pitch P2.9, P3.9, P4.8, P6.2, P7.8 and P10.4 are available from Yonwaytech Squared series LED display, offers stunning visuals with its diverse pixel pitches lets you choose which pixel pitch best fits your installation area and project requirements.

Fast front and rear dual maintain.

The modules, power supply, receiving card, and other components can be disassembled from the front, which is convenient for the maintainer to maintain the LED screen.

At the same time, traditional rear maintenance is also supported,LED Modules also come with hassle-free rear maintenance with its six-back locker system that allows easy dismantling of each module, which is time-saving and user-friendly.

Experience space-saving convenience with Yonwaytech Squared Series LED screen easy front maintenance design that allows you to streamline your installation site without requiring a large backspace.

You could choose anyone according to the actual situation.

Universal modules size and cabinet size.

The module size of all pitches is 500x250mm a whole series.

Different pixel pitches own same module back shell design, so the same cabinet frame can be replaced with different pitch module, and one cabinet frame can be reused to save cost.

Excellent heat dissipation and fanless operation

All aluminum material is more durable and highly stable than traditional steel one.

Meanwhile, heat dissipation of aluminum is much better than others in the market.

As the electronic components can be cooled down quickly, their lifespan will be longer.

Thermally conductive silicone grease was pasted between the power supply and cabinet.

Its main function is to make the power supply and the cabinet stick together better and improve the power supply’s heat dissipation ability.

Cable free LED module with dual pins.

Yonwaytech Squared LED Display doesn’t require the ribbon cable inside, stable and visually-appealing screen because of its cable-free HUB design. What’s more, we use signal pin dual sockets which is not only easy to replace modules, but also increase module usage.

Cable-free HUB design also makes a neat and clutter-free display, making viewing a lot friendlier and smoother.

Protective IP65 Dual Faces.

The LED screen in outdoor scenes will face more challenges than the indoor ones such as the damage of dust and water from long term work.

To make the LED screen function safely and stably in outdoor scenes, we adopt advanced protective methods to withstand heavy rain and strong winds for a long time.

The IP65 dual faces design can isolate electronic parts from humidity and dust, so the screen is more reliable.

Hight Brightness up to 10,000nits

To display clearly what is on the LED screen in outdoor scenes, we adopt the new methods of superior PCB design and LED chip

to make brightness reach more than 10000nits.

With the ultra-high brightness, refresh rate and gray scale, the visual performance of the screen is unexceptionable.

Support 3D LED Video Wall Technology

Yonwaytech Squared Series LED Display supports innovative 3D technology by offering the gapless cabinet splicing in the corner.

Seamless design, 90-degree Squared Series LED module allows smooth angles for making creative LED screens with different curves and flexibility.

At the same time, super light weight cabinet reduces the pressure of building structure.

High quality screen keeps helping the realization of new technology and shines the public.

Nike Japan’s Air Max Day 3D Billboard

Yonwaytech Squared series led display makes way for energy-efficient applications with its energy-saving properties and vibrant and cutting-edge displays.

To fit every different scene, our products utilize superior materials with a concise and strong structure, and various installation methods make it flexible and easy to apply.

Technical Parameters:
