Elite Series Rental Led Display P1.5,P1.9,P2.5,P2.6,P2.9,P3.9,P4.8 concert church stage rental led screen
The Elite series rental LED display,500x500mm or 500x1000mm panel size, configured with quick lock and corner
protection design,supports front and rear service design, and the power box is removable for easy maintenance.
Optional curved locks and beveled cabinets allow for unique installations.
Stage event being more and more popular, elements of stage contains lighting / audio / video……,
LED display playing an important role in Wholesale Church Signs video, used for Live interaction, Video broadcast etc.
Yonwaytech LED Display
Your Trustworthy One-stop Stage Event Rental LED Screen Factory Vendor Led Display Wholesale, the latest rental LED screen new design incorporates
many aesthetic elements, adopts high strength die-casting aluminum, and has better performance with a high-definition
visual Pantallas Led display.
Details speak louder words, friendly module and cabinet handles, cabinet fixing grooves and location pins, quick locks, corner protectors, removable power boxes, etc.
Elite Series LED Rental Display P1.5,P1.9, P2.5 event led display, P2.6,P2.9,P3.9,P4.8 optional for your various event visual needs.
Ultra light weight die-casting aluminum portable cabinet,ultra-thin thickness, friendly design make led display easy to use.
Light weight led panels makes the LED display easy to carry, transportation and install, saving a good amount of money on your labor costs.
A strong and reliable led display cabinet structure not only important during event show safe, but also good for your business ROI.
Humanization design led cabinet handles,quick assembly.
YONWAYTECH elite series stage rental LED screen with innovative structural design, and avant-garde body lines, giving you
an extraordinary experience for indoor and outdoor use with frontal and rear dual maintenance in LED Panels and
Power Box,easier in installation of led panels.
Optimized back integrated control box (includes power supply and control cards) has HUB linked with cabinet,can
be quick removable without any tools for replacement and maintenance,but also ip65 waterproof more reliable.
The LED panels are equipped with magnets and can be easily removed from the front side using tools in just 5 seconds.
Corner protectors for LEDs configured in panel
Yonwaytech Wholesale Led Display Elite series stage rental LED screen front service LED sign has four corner protectors in each
corner of panel to prevent LED to be damaged,especially more security during transport, installation, operation, assembly and
disassembly. This ensures the longevity and durability of the display in diverse working conditions.
High precision and humanization design curved rotating Locks
The Elite series stage rental LED screen configured with high precision curved Lock design is adopted to curved locks or
right-angle shape event led display installation to meet some special buildings and applications.
Seamless LED Display and Better Visual Effects
High precision aluminum cabinet frame makes seamless splicing image and video display,offering you the perfect
visual experience you desire from any angle.
The picture quality confronts viewers with an entirely new sensory experience.
High Refresh Rate, High Contrast, High Grey Scale, Bright Color.
Refresh rate of YONWAYTECH Led Display Supplier Elite series stage rental LED screen can be achieved in 3,840hz or
7,680hz fully matching the demand of live feed switching, even under 1/2000 shutter professional camera shooting.
Gob Led Display surface optional,especially in Elite rental led display small pixel pitch like 1.5mm and 1.9mm,can be with excellent proof of
moisture / salinity / static / dust / collision, etc.. brings more protection for your led display where located environment with high
salty or humidity.
YONWAYTECH Elite series stage rental LED screen with well flexibility and ease of installation make it ideal for temporary
events and long-term use. Not only good for stage rental temporary use,but also available in digital led billboard fixed installation.
IP65 outdoor water proof makes more reliable in outdoor environment.
rental LED display is widely used in various scenarios, including event sites, exhibitions, etc.
Ultra-wide viewing angle give you the largest screen viewing area
Viewing angle up to 160° in vertical and horizontal,providing a wide viewing angle, Ultra-wide viewing angle give you the largest
led screen viewing area.Audiences seeing from any angles, the stage rental led display would still being a natural and vivid image.
Yonwaytech Elite Indoor Rental LED Display Technical Parameters:
Model | P1.5(GOB) | P1.9(GOB) | P2.5 | P2.6 | P2.9 | P3.91 |
Pixel pitch(mm) | 1.56mm | 1.95mm | 2.5mm | 2.604mm | 2.976mm | 3.91mm |
Pixel Density / SQM | 409,600 | 262,144 | 160,000 | 147,456 | 112,896 | 65,536 |
Pixel Configuration | SMD1212 | SMD1515 | SMD2020 | |||
Brightness(nits) | ≥600 nits | ≥800 nits Adjustable | ||||
Drive Mode | 1/40 | 1/32 | 1/25 | 1/32 | 1/28 | 1/16 |
Power Con.(Max/Avg) | ≦450W-650W/sqm(Max.) / 150~190W/sqm(Avg.) | |||||
Module Dimension | 250mm x 250mm / 9.84″ x 9.84″ (W x H ) | |||||
Module Solution | 160 x 160 | 128 x 128 | 100 x 100 | 96 x 96 | 84 x 84 | 64 x 64 |
Cabinet Dimension | 1000mm x 500mm x 84mm & 39.37″ x 19.69″ x 3.31″ (W x H x D) 500 x 500mm x 84mm & 19.69″ x 19.69″ x 3.31″ (W x H x D) |
|||||
Cabinet Solution | 320dots x 320dots 320dots x 640dots |
256dots x 256dots 256dots x 512dots |
200dots x 200dots 200dots x 400dots |
192dots x 192dots 192dots x 384dots |
168dots x 168dots 168dots x 336dots |
128dots x128dots 128dots x 256dots |
Cabinet Weight | 500mmx500mm,8kg / 500mmx1000mm, 14.5kg. | |||||
Cabinet Material | Die-casting Aluminum | |||||
Serivice Access | Front & Rear | |||||
Refresh Rate(Hz) | ≥3840-7680 Optional | |||||
Grey Scale(Bit) | ≥16 | |||||
Contrast Ratio | 5000-10000 : 1 | |||||
Color Temperature | 3,000k–10,000k Adjustable | |||||
Color Uniformity | >97.5% | |||||
Brightness Uniformity | >97.5% | |||||
Viewing Angle(H/V) | Horz.:≥160° / Vert.:≥140° | |||||
IP Rate | IP31 Front / IP 31 Rear | |||||
Input Voltage(AC) | AC90-264V,47-63Hz | |||||
Operating Temperature | -20°C to +60°C / 4°F to 140°F | |||||
Operating Humidity | 10~90%RH | |||||
Lifespan(hrs) | ≥100,000(hrs) | |||||
Transmission Distance | CAT-5E≦120m,Multi-mode Optical Fiber≦500m,Single Mode Optical Fiber≦12km | |||||
Cabinet installation type | Fixed digital signage hanging & mounted / Rental stage backdrop | |||||
Warranty | 2-5 years standard product warranty optional |
Yonwaytech Elite Outdoor Rental LED Display Technical Parameters:
Model | P2.6 | P2.9 | P3.9 | P4.8 |
Pixel pitch(mm) | 2.604mm | 2.976mm | 3.91mm | 4.81mm |
Pixel Density / SQM | 147,456 | 112,896 | 65,536 | 43,264 |
Pixel Configuration | SMD1415 | SMD1921 | ||
Brightness(nits) | ≥4000 nits Adjustable | ≥5000 nits Adjustable | ||
Drive Mode | 1/16 Or 1/32 | 1/14 Or 1/28 | 1/8 Or 1/16 | 1/7 Or 1/13 |
Power Con.(Max/Avg) | ≦450W-800W/sqm(Max.) / 250~350W/sqm(Avg.) | |||
Module Dimension | 250mm x 250mm / 9.84″ x 9.84″ (W x H ) | |||
Module Solution | 96 x 96 | 84 x 84 | 64 x 64 | 52 x 52 |
Cabinet Dimension | 1000mm x 500mm x 84mm & 39.37″ x 19.69″ x 3.31″ (W x H x D) 500 x 500mm x 84mm & 19.69″ x 19.69″ x 3.31″ (W x H x D) |
|||
Cabinet Solution | 192dots x 192dots 192dots x 384dots |
168dots x 168dots 168dots x 336dots |
128dots x128dots 128dots x 256dots |
104dots x104dots 104dots x 208dots |
Cabinet Weight | 500mmx500mm,8kg / 500mmx1000mm, 14.5kg. | |||
Cabinet Material | Die-casting Aluminum | |||
Serivice Access | Front & Rear | |||
Refresh Rate(Hz) | ≥3840-7680 Optional | |||
Grey Scale(Bit) | ≥16 | |||
Contrast Ratio | 5000-10000 : 1 | |||
Color Temperature | 3,000k–10,000k Adjustable | |||
Color Uniformity | >97.5% | |||
Brightness Uniformity | >97.5% | |||
Viewing Angle(H/V) | Horz.:≥160° / Vert.:≥140° | |||
IP Rate | IP65 Front / IP 65 Rear | |||
Input Voltage(AC) | AC90-264V,47-63Hz | |||
Operating Temperature | -20°C to +60°C / 4°F to 140°F | |||
Operating Humidity | 10~90%RH | |||
Lifespan(hrs) | ≥100,000(hrs) | |||
Transmission Distance | CAT-5E≦120m,Multi-mode Optical Fiber≦500m,Single Mode Optical Fiber≦12km | |||
Cabinet installation type | Fixed digital signage hanging & mounted / Rental stage backdrop | |||
Warranty | 2-5 years standard product warranty optional |
